1. the assembled structure between the cabinets can be freely selected; the volume is small, neat and beautiful, occupying less space on the installation site; light weight, convenient for installation and maintenance.
2. the outer casing is made of high-strength, corrosion-resistant, heat-stable glass fiber unsaturated polyester resin or high-quality stainless steel plate.
3. adopting the patented technology of the combined explosion-proof distribution box independently developed, the modularized optimization design and combination of the distribution box makes the whole distribution box structure more compact and better in use; according to the requir-
ements of any combination of the various circuits, the configuration requirements of the power distribution equipment in different places are greatly improved.
4. the industry's first and most recently developed large-scale (current) flameproof single-unit circuit breakers (250a, 100a, 63a ex modules) can meet the supporting use of increased safety all-plastic distribution boxes.
5. all exposed fasteners are made of stainless steel.
6. cable in and out of the line, according to user requirements can be made up and down, down and down, up and down, down and up and other forms.
7. the inlet and outlet ports are usually made of pipe threads, and the cable clamping and sealing device is arranged. it can also be made into metric thread, npt thread, etc. according to the requirements of the user site.
8. steel pipes and cable wiring are available.
9. the number of components and branches in the distribution box can be configured according to user requirements; outdoor products can be equipped with rain cover according to user requirements.
10. the installation method of the distribution box is generally hanging type, and it can be established, seat type or power distribution cabinet when special requirements.
